Palm kernel oil production process

As we all know, oil palm is a kind of important tropic oil seed plant. Rate of oil in oil palm is very high. Common fresh fruit flesh: 46%-50%, palm kernel: 50%-55%.

Each part of palm fruit bunches

Usually there are many palm oil mills in Nigeria, after processing palm fruit, palm kernel with fiber are remained. Many people sell palm kernel to others. In fact, palm kernel oil is more valuable than palm fruit oil. We Henan Doing Company are also engaged in manufacturing and supplying palm kernel oil production process machinery which can extract palm kernel oil efficiently. The whole palm kernel oil production process include palm kernel oil extraction process,palm kernel oil refinery plant and palm kernel oil fractionation process.The below is the detail introduction about palm kernel oil production process.

Palm oil production process, from this photo, you can know each stage of palm oil produciton process, you can get what palm oil products.

Palm kernel oil extraction process

How to produce palm kernel oil? What is the palm kernel oil production process? The following introduce will tell you:

First stage of palm kernel oil production process:

First, the palm kernel need go through a cleaning process to remove sand, stalk, plant debris and any other impurities These impurities are bad for palm kernel oil production process machinery, especial for the palm kernel oil expeller.

And then the palm kernel have to be crushed, because of the palm kernel is hard and big size, it is required to crush to smaller pieces.

Next the crushed palm kernel will be sent to palm kernel cooker to make it is suitable for pressing of palm kernel oil production process, doing like this can help user get the maximum oil and good quality cakes.

Finally, the prepared palm kernel will be sent to palm kernel oil expeller machine, due to strong frication and high pressure, palm kernel oil is pressed out. To this step , we can get crude palm kernel oil, but the oil contains some oil dregs , we need clarifying, and then use crude palm kernel oil filtering machine to filter the other Impurities to get crude pure palm kernel oil.

[Recommend reading: Palm kernel oil extraction machine]

Palm kernel oil extraction machine photos:

Palm kernel oil extraction machine

Second stage of palm kernel oil production process:

After palm kernel oil extrarction process , we can get crude palm kernel oil, the crude palm kernel oil can be eat deirectly, or sent to the palm kernel oil refinery plant for further processing to get refinery palm kernel oil, The following is palm kernel oil refinery process:

First stage of palm kernel oil refinery plant is to remove Free Fatty Acids (F.F.A.) with caustic soda treatment called Neutralizing Process, thereafter further processed in the bleaching section under vacuum & treated with bleaching earth & activated carbon for removing colour. Finally it will be deodorized under high vacuum and high temperature to remove the odour from the oil.

[Recommend reading: Palm kernel oil refinery plant ]

Palm kernel oil refinery plant photos:

Palm kernel oil refinery plant

Third stage of palm kernel oil production process:

After palm kernel oil refinery process, we can get refined palm kernel oil . But if you want to get palm kernel oil olein and palm kernel oil stearin , you need to buy palm kernel oil fractionation plant.

Palm kernel oil fractionation process is the latest palm kernel oil production process. Palm kernel oil fractionation plant can greatly maximize the value of products. The palm oil production process is as follows:

Palm kernel oil fractionation process is another major process in palm kernel oil production process. Palm kernel oil fractionation process devides into 3 parts, crystallazing, crystall growing/maturing, and filtration.After palm kernel oil fractionation process, palm kernel oil is separated to several parts with different melting points, which can be used in different industrial usages.

Palm kernel oil fractionation plant photos:

Palm kernel oil fractionation plant

We have been specialized in palm kernel oil production process machinery for decades. Our professioanl engineers can help you design and install palm kernel oil production process machinery according to your capacity and requirements. Once you signed contract with Henan Doing Company, we will supply palm kernel oil mill plant layout, palm kernel oil extraction process flow chart and others. Please hurry up to contact with us.
