A brief introduction of palm oil production line
 Palm oil production line |
 Palm oi milling process |
Henan Doing Mechanical Equipment Co is a professional palm oil production machine manufacturer. We could offer customer whole line palm oil production machines with capacity 500kg/h-5t/h-10t/h-20t/h-30t/h-60t/h,etc. Palm oil production machine line is very different from other common oil seeds. It mainly includes 9 sections:
1. Raw materials storage section of palm oil production:Fresh palm fruit bunch must be first measurement recorded by the pound into the plant, then unloaded to loaded fruit slopes and stored.
2. Sterilizing section of palm oil production: fresh palm fruit bunch are airtight sterilized in sterilizer. The purpose is to prevent enzymes broken down, avoiding FFA content in oil further increase; easy threshing machinery; pretreatment peel, prepared for the follow-up processing; pre-conditioning stone, reducing the damage kernel.
3. Threshing section of palm oil production: The purpose of threshing is to separate oil palm fruit from the fruit bunch through strong vibration.
4. Palm oil pressing section of palm oil production: Before pressed, oil palm fruit first be carried out cooking, sterilized fruit must be re-heated to make the pulp soft and damage pulp cell structure. Then enter into continuous screw press.
5. Palm oil clarification section of palm oil production: Machine-pressed crude oil first diluted with water washing, the fiber material removed from the oil through settlement and filtration, and then carry out continuous settlement.
6. Finished crude palm oil is stored in storage tanks.
7. Fiber separation section of palm oil production: Press cake broken by breaking screw conveyor and then transported into the fiber separation air net and fiber polishing roller for fiber separating.
8.Kernel recovery section of palm oil production: After separation, shell is sent to the warehouse for temporary storage, as boiler room fuel when necessary; Dried kernel is sent to kernel storage warehouse for storing.
9.Sewage treatment section of palm oil production: Pool sewage treatment system is the most used and effective treatment.
If you are interesed in palm oil production line, please feel free to contact me.
