Palm fruit oil pressing machine

Palm fruit oil pressing machine is the main equipment to extract palm oil. Palm fruit oil pressing machine also named screw palm oil press which is the most economic palm oil extraction machine for palm oil production process. Meanwhile, mechanical presser is the most used palm fruit oil pressing machine. In palm fruit oil pressing station, mechanical screw palm fruit oil pressing machine is used to extract the oil out form digested palm pulp. After palm fruit oil pressing machine we can get a mixture of oil, water, fibre and nuts.

palm fruit oilpressing machine From palm pulp to crude red palm oil

Because of cooking, sterilizing, threshing and digesting made the pulp soft and damage pulp cell structure, the palm pulp becomes soft and cell is broken. Then it is sent to continuous screw palm fruit oil pressing machine. After pressing, oil palm fruit is divided into two parts: the mixture of oil, water and solid impurities, and the press cake (fiber and nut).

palm fruit oil pressing machine Big capacity palm fruit oil pressing machine

How to work the palm fruit oil pressing machine?

When palm fruit oil pressing machine is running, sterilized and digested palm fruit enter the pressing chamber from the hopper and then moves forwards by the rotating screw. In dynamic state semi-fluid materials are processed inside the pressing chamber, under the high pressure of pressing chamber and rotating screws, friction will be created between material and screws, material and pressing chamber. It also creates friction and relative movement among material particles. On the other hand, root diameter of the pressing screw varies from one side to the other. Hence, when rotating, it not only pushes particles moving but turns them outwards of the center screws as well. Meanwhile particles adjacent the screw will rotate along with screw’s rotating, causing every particles insides the chamber to move towards the middle of double screws, the spacious of pressed materials are compressed continuously, and the minimum gap of double screw are bigger than size of palm nut, it not only resulting in high oil productivity but also ensure the completeness of palm nuts under the protection of covered fiber, enable the deep processing of palm nut.

palm fruit oil pressing machine Palm fruit oil pressing machine is on working

As professional manufacturer of palm oil processing plant, we can supply big capacity palm fruit oil pressing machine, small palm fruit oil pressing machine and mini palm fruit oil pressing machine. The above is the big capacity palm fruit oil pressing machine introduction, Next i will introduce small palm fruit oil pressing machine and mini palm fruit oil pressing machine to you.

1tph,2tph double screw palm fruit oil pressing machine:

This unique designed double screw palm fruit oil presssing machine can extract palm oil effectively.The continuous double-screw palm oil press and the hydraulic automatic control system for adjusting the pressure inside the press cage ensure high pressing efficiency, low oil residue in cake mash and low breakage of palm nuts.

palm fruit oil pressing machine 1tph palm fruit oil pressing machine

1tph double screw pam fruit oil presssing machine 3D animation:

palm fruit oil pressing machine 1tph double screw palm oil pressing machine

Technology parameters of 1tph palm fruit oil pressing machine:

Product name : 1tphdoublescrewpalmoilpresser
Power: 7.5KW
Screwdiameter: 146mm
Screwdistance: 127-135mm
Length*Width*Height 2500*1000*550mm
ReferenceWeight: 1800kg
Oillossindryfiber: 6%-8%
Nutbreakage: 8%-10%
Powerofhydraulicunit: 2.2KW

300-500kg/h mini palm fruit oil pressing machine:

300-500kg/h mini palm fruit oil pressing machine also called palm oil extraction machine ,palm oil expeller machine or palm oil extractor machine. 300-500kg/h mini palm fruit oil pressing machine has resonable structure, which is easy to operate and maintain. The small palm oil press machine can be fitted with motor or diesel engine.The capacity of this small palm oil press machine is 8-12TPD(tonnes per day), which is the best selection for small capacity palm oil production. The final oil is edible red oil.

palm oil pressing machine

300-500kg/h palm fruit oil pressing machine 300-500kg/h palm fruit oil pressing machine 3D animation:

palm fruit oil pressing machineSmall scale palm fruit oil pressing machine

Technology parameters of 300-500kg/h palm fruit oil pressing machine:

Capacity(kg/h) 300-500
MainPower(kw) Diesel:8HP

Moter:4Kw

MainShaft Speed 25-35r/min
BoilingTime 2h
Weight(kg) 350
PackedSize(mm) 1500*800*1200

Features of 300-500kg/h palm fruit oil pressing machine :

1.Small scale palm oil extraction machine mainly used to extrude palm fruit oil.

2.Designed and manufactured by Henan Doing company

3.It's good for small scale farm, small palm oil factory, home using,

4.Easy operation, easy move, easy change place

5.Driven by motor or diesel engine

6.Popular in Africa, South Africa, South America, Cameroon, Thailand, Ghana, Nigeria, etc.

More read: Newest design YL-130 small palm oil press machine

Small palm oil press machine/expeller pressed palm oil machine video

No matter you need big capacity palm fruit oil pressing machine, small palm fruit oil pressing machine, or mini palm fruit oil pressing machine. As an reliable palm oil processing plant manufacturer on the market, after years of business, Henan Doing Company has gained reputaions around the world in palm oil machine field. If you are a new comer of palm oil processing business and want to set up a small scale palm oil mill plant, we will be your best guide and you can trust both the quality of our machine and the after services we offered. Feel free to inquire about the latest cost and detailed equipment list of palm oil production machine.
